Türkçe PROCCESING PARAMETERS
The recommended temperatures for ATABOND® resins are as follows;
| ZONE | PE –BASED GRADES | PP –BASED GRADES |
|---|---|---|
| ZONE 1 | 170 - 200 (°C) | 200 - 230 (°C) |
| ZONE 2 | 170 - 200 (°C) | 200 - 230 (°C) |
| ZONE 3 | 200 - 230 (°C) | 200 - 250 (°C) |
| ZONE 4 | 200 - 230 (°C) | 200 - 250 (°C) |
| AD | 200 - 230 (°C) | 200 - 250 (°C) |
| DİE | 200 - 230 (°C) | 200 - 250 (°C) |
| MELT TEMPERATURE | 200 - 230 (°C) | 200 - 240 (°C) |
- Maximum temperature: 280-300°C
- Temperatures above the upper limit or long residences times of molten resin may lead to decomposition of the polymers.
- Decomposition products may be Carbondioxide, Carbonmonoxide, Hydrocarbons and water.
SHUTDOWN
The following procedure is recommended whilst the extrusion process is either interrupted or terminated.
- Less than 2 hours: Screw rotation can be stopped while maintaining temperature.
- More than 2 hours: Purge out and shut down in accordance with common procedure.
PURGİNG
Below, you will find the recommended purging materials and their extrusion temperatures for a permanent shutdown.
| PE –BASED GRADES | PP –BASED GRADES | |
|---|---|---|
| Material | PE ( MFI: 1) | PE (MFI:1) |
| Temperature | 200 - 230 (°C) | 200 - 240 (°C) |
STORAGE
ATABOND® resins are supplied in form of small, free flowing pellets and can be easily handled with commercially available equipment.
- Store and transport at a temperature below 50 °C
- Protect from moisture
- Store the tightly sealed containers in a dry, cool, and well-ventilated location
